| Model | 1561E-IDT |
| Case/Bezel Color | Black/Silvery/white(Customized) |
| Display Size | 15.6" |
| Style | True Flat |
| Touch panel (True-flat Style) | Projected Capacitive touch screen (Resistive touch screen optional) |
| Touch response time | 8ms |
| Touchcomputors Dimensions | 391.6x 201.1 x 318 mm |
| LCD Type | TFT LCD(LED backlight) |
| Useful Screen Area | 345.5 mm x 195 mm |
| Aspect ratio | 16:9 |
| Optimal (native) Resolution | 1920 x 1080 |
| LCD panel Pixel pitch | 0.17925 x 0.17925 mm |
| LCD panel Colors | 6bit Hi-FRC |
| LCD panel Brightness | 220 cd/m2 |
| LCD panel Contrast Ratio | 500:1 |
| LCD panel Response Time | 12 ms |
| Viewing Angle | Horizontal | ±45° or 90° total |
| (typical, from center) | Vertical | -20°~+40° or 60° total |
| output Video signal connector | Mini D-Sub 15-Pin VGA type and HDMI type |
| Input interface | 2*USB 2.0 & 2*USB 3.0 & 2*COM(3*COM optional) |
| 1*Earphone1*Mic1*RJ45(2*RJ45 optional) |
| Extend interface | 2*USB2.02*COM1*PLT2*PCI-E(4G SIM card, 2.4G&5G wifi & Bluetooth module optional) |
| Power Supply Type | Monitor input: +12VDC ±5%,5.0 A; DC Jack (2.5￠) |
| AC to DC power brick input: 90-240 VAC, 50/60 Hz |
| Power Consumption: less than 60W |
| ECM (Embed Computer Modul) | ECM2: Intel processor J1800 (Dual Core 2.41GHz,Fanless) |
| ECM3: Intel processor J1900 (Quad-core 2.0GHz/2.4GHz,Fanless) |
| ECM4: Intel processor i3-4010U (Dual Core 1.7GHz,Fanless) |
| ECM5: Intel processor i5-4200U (Dual Core 1.6GHz/2.6GHz Turbo, Fanless) |
| ECM6: Intel processor i7-4500U (Dual Core 1.8GHz/3GHz Turbo, Fanless) |
| CPU Upgrade:3855U & I3-I7 series 5th 6th 7th optional |
| SATA3:HDD 500G(up to 1TB optional);SDD 32G(up to 128G optional) |
| Memory: DDR3 4G(extend up to 16G Optional) |
| ECM8: RK3288 Cortex-A17 quad-core 1.8G, GPU:Mali-T764;Operation System: 5.1 |
| ECM9: RK3368 Cortex-A53 8Core 1.5GHz;GPU:PowerVR G6110;Operation System: 6.0 |
| ECM10:RK3399 Cortex-A72+Cortex-A53 6-Core 2GHz;GPU:Mail-T860MP4;Operation System: 7.1 |
| Rom:2G(up to 4G optional);Flash:8G(up to 32G optional) |
| Temperature | Operating: 0°C to 40°C ;Storage -20°C to 60°C |
| Humidity (non condensing) | Operating: 20%-80%; Storage: 10%-90% |
| Shipping Carton Dimensions | 450 x 280 x 470 mm(with stand);470 x 210 x 420 mm(without stand) |
| Weight (approx.) | Actual: 6.8 kg ;Shipping: 8.2 kg |
| Warranty Monitor | 3 years(Except for LCD panel 1 year) |
| Backlight lamp life: typical 50,000 hours to half brightness |
| Agency Approvals | CE/FCC RoHS (UL & GS customized) |
| Mounting Options | 75 mm and 100mm VESA mount(Remove Stood) |
